3U (3 x 5.25" + 5 x 3.5" HDD Bay) Rackmount Chassis

(14.96" Deep) (ATX / Micro-ATX / Mini ITX) Server Case

Support Standard ATX PS2 / PS3 size PSU

IPC-3035S


pad













PRODUCT TECHNICAL SPECIFICATIONS

The era of ATX and Micro-ATX constructed Dual-core and Quad-Core CPU platforms have been the mainstream nowadays, the fast and stable server system is also presented by this model of design, the major feature of this brand new design is the depth of this chassis has 380mm only, it supports the most cost effective and stable quality, combines with two intake 80mm fans at front side as standard and two exhaust 60mm fans at rear panel as option, comes with totally 6 drive bay with the chassis configuration, fits all standard 12"x9.6" Intel ATX MB form factor and standard PS2 power supply, meets regular server system application.

  • Totally 7 drive bay: (if MB is 12"x9.6" ATX)
     2 x 5.25" CD and 5 x 3.5" HDD bay (pic1, pic2)

  • Totally 8 drive bay: (if MB is 9.6"x9.6" Micro-ATX)
     3 x 5.25" CD and 5 x 3.5" HDD bay

  • Totally 8 drive bay: (if MB is 9.6"x9.6" Micro-ATX)
     2 x 5.25" CD and 6 x 3.5" HDD bay

  • Totally 9 drive bay: (if MB is 9.6"x9.6" Micro-ATX)
     2 x 5.25" CD and 5 x 3.5" HDD and 2 x 2.5" HDD  bay

  • HDD bay with anti-vibration function supported

  • Equipped two USB 2.0 port at front bezel

  • Main structure of sheet metal by high-class SGCC 1.2mm~2.0mm thickness

  • equipped with two 80mm x 25mm intake YATE LOON D80SM-12C fans with air filter at front bezel

  • MB: ATX(12"x9.6")‧Micro-ATX(9.6"x9.6")‧Mini ITX(6.7"x6.7")

  • Support PS2 power supply with 8cm or 12cm~14cm fan version (max. psu depth at 140mm~180mm)

  • If 14cm deep PS2 psu installed, 5.25" ODD device by 21cm deep also compatible

  • If 18cm deep PS2 psu installed, 5.25" ODD device by 17cm deep also compatible

  • If front fixed with 3.5" HDD, 4 slot full high plugin cards (max. depth at 170mm)

  • If front fixed w/o 3.5" HDD & bracket, 4 slot full high plugin cards (max. depth at 330mm)

  • standard paint: black

  • chassis dimension: 19" x 3U x 380mm (14.96" deep)

pad
border=0


 Dimension Drawing

Inside  Drawing

Chassis Quick Manual

Our Price:pad$70.00

(The pricing does not include MB, HDDs and rail set on the pictures)

Availability: Usually ships the next business day
Part#: IPC3035S-BK
Ground Shipping: $30.00
Canada : $55.00
Alaska/Hawaii: $80.00

  IPC3035S-BK-V2 - Black
Visa ,MasterCard, Discover, and American Express

Accessory optional (Free Shipping for purchasing w/ Chassis)

Brand

Item Price
5.25" Programmable USB 20x4 character LCD module, six button keypad PLCD-525 $115

Optional 2 x 60mm x 25mm YATE LOON D60SM-12

$5
USB 3.0 module $10

Athena Power 400W PS3 MPS3ATX40 $32

Sparkle 400W ATX-400PA-B204 $45

80+ 600W EPS12V PS3 MPS3ATX60FEP8 $120
Sparkle 650W EPS12V i7 P4 FSP650-80GLC $98



24in 2 Layer 3 Travel 2 x Universal Slide Rail & 4 x Rail Holder $40
Black 20in Slide Rail & Rail Holder for  2 x rails and 4 x L-type brackets $30

Black 26in Slide Rail & Rail Holder for  2 x rails and 4 x L-type brackets $40

4 Post Rear Mount and 2 post Central Mount brackets $10
Aluminum 1 x 5.25"  to 4x2.5" SAS/ATA Hot-Swap Cage Backplane TL-225_525 $22
Aluminum 1 x 5.25"  to 4x2.5" SAS/SATA Hot-Swap Cage Backplane RW-425 $52
Aluminum 1 x 5.25" to 6x2.5" SATA Hot-Swap Cage Backplane RW-625 $60
5.25" to 8x2.5" SATA Hot-Swap Cage Backplane RW-1825 $98
Aluminum 1 x 5.25" to 1x3.5" SAS/SATA TrayLess Hot-Swap Cage Backplane TL-135 $25
Aluminum 2x5.25" to 8x2.5" SAS/SATA Hot-Swap Cage Backplane RW-825 $80

Aluminum 3x5.25" to 12x2.5" SAS/SATA Hot-Swap Cage Backplane RW-1225 $100
Aluminum 2 x 5.25" to 3x3.5" SAS/SATA TrayLess Hot-Swap Cage Backplane TL-335 $55
Aluminum 3 x 5.25" to 5x3.5" SAS/SATA TrayLess Hot-Swap Cage Backplane TL-535 $85
Universal 5.25" Bay  to 3.5" HDD or 3.5" HDD Bay to 2x2.5" HDDs $5

HDD Bracket for 5.25" Bay $5
