1U
Intelligent Green Saving LCD Display & Fan Control (Maximum 12 x 2.5"
HDD/SSD HDD Bay compatible) Rackmount Chassis
(1U Flex
ATX PSU) (1 Horizontal slot full high cards by
Riser Card)
(12.60" Deep) (Micro-ATX / Mini ITX) Server Case
IPC-G1320M |
|

|

|

|
 |
 |

Optional
Back I/O shield
(Picture show as 1UIODG45FC / Intel
DG45FC Mini-ITX LGA775 I/O shield / Compatible with Intel
BOXDG45FC LGA 775 G45 Mini ITX Intel MB)

|
PRODUCT
TECHNICAL SPECIFICATIONS
-
Drive capacity:
12
x 2.5" HDD/SSD (height
9.5mm HDD/SSD
& height 64.4mm low profile card
compatible)
or 6 x 2.5" HDD/SSD (height
15mm HDD/SSD &
height 64.4mm low profile card compatible)
or 2 x 15mm high
2.5" HDD/SSD & 4 x 9.5mm
high HDD/SSD (full height card compatible)
or
4 x 15mm high 2.5"
HDD/SSD (full height card compatible)
or 1 x 3.5" HDD & 4
x 9.5mm high 2.5" HDD/SSD (expansion
card is not compatible)
or 1 x 3.5" HDD & 2 x 15mm
high 2.5" HDD/SSD (expansion card is
not compatible)
-
Intelligent EnergySaving device's
default is all fans automatically
activated if system temperature up to 38 degree-C
-
Intelligent EnergySaving device's default is 38
degree-C but
individual fan can be adjusted between 30~60
degree-C
-
Intelligent EnergySaving device supported with
four
fan fail's indication and warming
(stop warning by any button)
-
Intelligent EnergySaving device supported with
Celsius or Fahrenheit Degree
(convertible by C/F button)
-
I/O
front access rackmount
ears included
as standard component
-
Optional
fan
connecting PCB when optional
extra 4 fans installed (part#
PCB-FAN-S)
-
Note:
if 3.5" HDD installed, the expansion
card function is not available
-
Equipped two
USB 2.0 port as well
as internal display LAN/HDD/Power LED lights on
front bezel
-
Mechanism
made by
high & clean grade Korean SECC sheet metal by 1.0mm~2.0mm
thickness
-
Two
brand new & silent
40mmx20mm intake cooling fans (YATE
LOON part# D40SM-12C)
-
Compatible MB: MicroATX 9.6"x9.6", Deep Mini-ITX
6.7"x8.2", Mini-ITX 6.7"x6.7"
-
Various
PLinkUSA / RackBuy 1U
I/O shield
selectable (option, increasing new I/O
shields every week)
-
Support standard 1U FlexATX
250W~500W power supply (maximum
power depth: 150mm)
-
Support
1 slot full high expansion card (max. 275mm
long) (Riser card does not include)
-
Standard
paint: scratch-resistant black textured at front and rear
-
Removable rear switch / LED to be
ventilation
-
Chassis
dimension:
19" x 1U x 320mm (12.6" deep)
-
Package:
NW 4.0 KG, GW 5.4 KG, 1.4 CUFT (57x45x15.5cm, single box packed)
-
Accessory
pack: #6 round x8, M3
countersunk x12, M3 truss x48, #6
countersunk x4, #6 countersunk black x3,
ear x1 pair
-
Green Energy saving server
patent pending areas: China, Taiwan, Thailand, Korea, Japan, USA, UK,
EU, Russia
-
Patent and Law attorney
agency: China GuanDong Kwo Hui Attorney at Law
|
 |
|
|
|
|
|
a.
Dimension
Drawing
b.
Chassis quick assembly manual |
Our Price:
$100.00
(The
pricing does not include MB, HDDs and rail set on
the pictures) |
Availability:
Usually ships the next business day |
Part#: IPC-G1320M-BK |
Ground Shipping: $45.00 |
Canada :
$80.00 |
Alaska/Hawaii:
$70.00 |
|
|
|
ITX-G1320M-BK - Black |
 |
|
|
|
