Picture of PAPTX-AGP

Multi Riser card for AGP/PCI/PCI Express

If you are not sure what card you need, send email to us include your MB model # and what slot you will use


(PS3 Size 400W PSU) Good for (Short Depth 2U/3U Rackmount Chassis)

(IPC-2022M, IPC-1013S and IPC-3035S)

HP Pavilion Series / Dell / Compaq Presario

AP-MPS3ATX40
pad



PRODUCT TECHNICAL SPECIFICATIONS

  • Output over voltage protection

  • Short circuit protection on all outputs

  • Reset table power shut down

  • Approved by UL, TUV, CB & CE

  • Internal 12 VDE fan

  • Complies with Fcc part 15 subpart J Class B at 115 VAC operation & CISPR 22 Class B at 230 VAC operation

  • 100% burn-in under high ambient temperature (50centJ)

  • Vacuum -impregnated transformer

  • MTBF: 100k hours at 25centJ

  • 100% Hi-pot tested

  • Full RANGE 190-264VAC (400W)

  • Dimension: 5.75” W x 4” D x 3.25” H

  • WITH HP VEDIO POWER CONNECTOR

  • AC INPUT: 115/230 Vac~ 10/5A 60/50Hz

  • DC OUTPUT:

  • COLOR BROWN RED WHITE YELLOW BLUE PURPLE BLACK GREEN ORANGE

  • DC +3.3V +5V -5V 12V -12V +5V-SB COM PS-ON PW-OK

  • OUTPUT 17A 16A 0.5A 11A 1.0A 2.0A RETURN REMOTE P.G.

  • (+3.3V and +5V Max Output 118W, Peak Surge Max Output 220W)

    •





padAP-MPS3ATX40

HP Pavilion 6330 HP Pavilion 6333 HP Pavilion 6336 HP Pavilion 6340 HP Pavilion 6343 HP Pavilion 6345
HP Pavilion 6346 HP Pavilion 6350 HP Pavilion 6353 HP Pavilion 6355 HP Pavilion 6356 HP Pavilion 6357
HP Pavilion 6360 HP Pavilion 6370 HP Pavilion 6370Z HP Pavilion 6375 HP Pavilion 6405 HP Pavilion 6408
HP Pavilion 6409 HP Pavilion 6410 HP Pavilion 6420 HP Pavilion 6425 HP Pavilion 6430 HP Pavilion 6460
HP Pavilion 6465 HP Pavilion 6466 HP Pavilion 6468 HP Pavilion 6470Z HP Pavilion 6475Z HP Pavilion 8510
HP Pavilion 8510 HP Pavilion 8520 HP Pavilion 8520 HP Pavilion 8525 HP Pavilion 8530 HP Pavilion 8530
HP Pavilion 8533Z HP Pavilion 8540 HP Pavilion 8543C HP Pavilion 8545 HP Pavilion 8545  HP Pavilion 8550
HP Pavilion 8550 HP Pavilion 8550C HP Pavilion 8555C HP Pavilion 8556C HP Pavilion 8560 HP Pavilion 8560C
HP Pavilion 8562 HP Pavilion 8565C HP Pavilion 8566C HP Pavilion 8570C HP Pavilion 8575C HP Pavilion 8576C
HP Pavilion 8578C HP Pavilion 8580C HP Pavilion 8586C HP Pavilion 8590C HP Pavilion 8595C HP Pavilion 8650C
HP Pavilion 8652C HP Pavilion 8655C HP Pavilion 8656C HP Pavilion 8660C HP Pavilion 8662C HP Pavilion 8665C
HP Pavilion 8668C HP Pavilion 8670C HP Pavilion 8674D HP Pavilion 8674F HP Pavilion 8676C HP Pavilion 8679F
HP Pavilion 8693C HP Pavilion 8694F HP Pavilion 8699F HP Pavilion 8700A HP Pavilion 8700A HP Pavilion 8700A
HP Pavilion 8700A HP Pavilion 8700A HP Pavilion 8700A HP Pavilion 8700A HP Pavilion 8700A HP Pavilion 8700A
HP Pavilion 8700I HP Pavilion 8700I HP Pavilion 8700I HP Pavilion 8700I HP Pavilion 8700I HP Pavilion 8700I
HP Pavilion 8700I HP Pavilion 8700I HP Pavilion 8705 HP Pavilion 8750C HP Pavilion 8754C HP Pavilion 8755C
HP Pavilion 8756C HP Pavilion 8760C HP Pavilion 8762C HP Pavilion 8765C HP Pavilion 8766C HP Pavilion 8770C
HP Pavilion 8772C HP Pavilion 8775C HP Pavilion 8776C HP Pavilion 8785C HP Pavilion 8860 HP Pavilion 8870
HP Pavilion 88XX HP Pavilion 9680C HP Pavilion 9682C HP Pavilion 9686C HP Pavilion 9688C HP Pavilion 9690C
HP Pavilion 9692C HP Pavilion 9694C HP Pavilion 9695C HP Pavilion 9780C HP Pavilion 9790C HP Pavilion KioskV2
HP Pavilion Misc. HP Pavilion XL753 HP Pavilion XL754 HP Pavilion XL756 HP Pavilion XL759 HP Pavilion XL761
HP Pavilion XL766 HP Pavilion XL768 HP Pavilion XL773 HP Pavilion XL775 HP Pavilion XL776 HP Pavilion XL795
HP Pavilion XL844; HP Pavilion XL866 HP Pavilion XL876 HP Pavilion XP788 HP Pavilion XP789 HP Pavilion 304w;
HP Pavilion 325c HP Pavilion 354n HP Pavilion 364n HP Pavilion 374n HP Pavilion 500 Pavilion 501
HP Pavilion 503 HP Pavilion 504 HP Pavilion 505 HP Pavilion 506x HP Pavilion 510 HP Pavilion 512
HP Pavilion 513 HP Pavilion 514 HP Pavilion 515 HP Pavilion 516 HP Pavilion 520 HP Pavilion 521
HP Pavilion 522 HP Pavilion 523 HP Pavilion 524 HP Pavilion 525 HP Pavilion 526 HP Pavilion 530
HP Pavilion 533 HP Pavilion 534 HP Pavilion 542 HP Pavilion 543 HP Pavilion 544 HP Pavilion 545
HP Pavilion 552 HP Pavilion 553 HP Pavilion 554 HP Pavilion 555  HP Pavilion 562 HP Pavilion 563
HP Pavilion 564 HP Pavilion 573 HP Pavilion 576 HP Pavilion 6470 HP Pavilion 700 HP Pavilion 701
HP Pavilion 702 HP Pavilion 703 HP Pavilion 704 HP Pavilion 710 HP Pavilion 711 HP Pavilion 712
HP Pavilion 713 HP Pavilion 714 HP Pavilion 716 HP Pavilion 720 HP Pavilion 721 HP Pavilion 722
HP Pavilion 723 HP Pavilion 724 HP Pavilion 725 HP Pavilion 730 HP Pavilion 731 HP Pavilion 732
HP Pavilion 733 HP Pavilion 734 HP Pavilion 735 HP Pavilion 740. HP Pavilion 741 HP Pavilion 742
HP Pavilion 743 HP Pavilion 744 HP Pavilion 746 HP Pavilion 750 HP Pavilion 751 HP Pavilion 752
HP Pavilion 753 HP Pavilion 7xx HP Pavilion 8xx HP Pavilion 9xx HP Pavilion XTxx HP Pavilion mxxx
Channel Well SFX-200PS3C   Presario 6485CL (0950-4107)
Dimension B100 Dimension 1100 Dimension 2200 Dimension 2300 Dimension 2350  Dimension 2400
Dimension 4300 Dimension 4400 Dimension 4500 Dimension 4550 Dimension 8200 Dimension 8250
Dimension 8300 OptiPlex 170L  OptiPlex GX50 OptiPlex GX60 OptiPlex GX150 tower systems PowerEdge 400SC
PowerEdge 600SC Precision WorkStation 340 Precision WorkStation 350 SmartStep 100D SmartStep 150D
Dimension 3000 Dimension 3100 Dimension 4600 Dimension 4700 Dimension 8400 Dimension 9100
Dimension E310 Dimension E510 OptiPlex GX280 Mini-Tower OptiPlex GX280 Mini-Tower Precision WorkStation 370


AP-MPS3ATX40_Dell-X



Dimension 2100 Dimension 4100 Dimension B1000R Dimension V400 Dimension XPS B, D, M, R, T Series Dimension XPS P133c MT
Dimension XPS XPS Pro 180n Dimension L-Series

(LxxxR, LxxxCXE, LxxxCX, and LxxxC)

 OptiPlex G1 tower systems OptiPlex GX1 tower systems OptiPlex GX110 OptiPlex GX115
OptiPlex GX300, GN, GN+, GXa, and GXi PowerEdge 2100 PowerEdge 2200 Precision WorkStation 210 Precision WorkStation 220 Precision WorkStation 400


AP-MPS3ATX40_Dell-P16



Dimension 8100 Precision 330 OptiPlex GX400 PowerEdge 1300 PowerEdge 2300 Precision Workstation 330
Precision Workstation 420






border=0
Click thumbnails to view larger photos
Our Price:pad$32.00
Availability: Usually ships the next business day.
Part#: AP-MPS3ATX40
Ground Shipping: $10.00
Canada : $25.00
Alaska/Hawaii: $40.00
AP-MPS3ATX40     Visa ,MasterCard, Discover, and American Express

Our Price:pad$39.00
Availability: Usually ships the next business day.
Part#: AP-MPS3ATX40_Dell-X
UPS Ground Shipping: $10.00
Canada : $20.00
Alaska/Hawaii: $40.00
AP-MPS3ATX40_Dell-X     Visa ,MasterCard, Discover, and American Express

Our Price:pad$39.00
Availability: Usually ships the next business day.
Part#: AP-MPS3ATX25_Dell-P16
UPS Ground Shipping: $10.00
Canada : $20.00
Alaska/Hawaii: $40.00
AP-MPS3ATX40_Dell-P16     Visa ,MasterCard, Discover, and American Express
